Product Details:
|
| Name: | Automated Palletizing Conveyor | Power: | 7500W |
|---|---|---|---|
| Material Feature: | Dust Protection | Voltage: | 220 V |
| Feature: | Heavy Duty | Package: | Wooden Box |
| Working Temp.: | More Than 100° | Controller: | One Controller For Whole Conveyor System |
| Highlight: | 7500W Automated Palletizing Conveyor,100kg Automated Palletizing Conveyor,7500W heavy duty pallet conveyor systems |
||
7500W Chain Driven Heavy Duty Automated Palletizing Conveyor Systems
Automated Palletizing Conveyor has the characteristics of large transport volume, high speed, light operation, and the ability to realize the transmission of multiple lines at the same time.
The Automated Palletizing Conveyor is applicable to transport the goods whose bottom is flat. For example: electronic, beverage, food, packaging, machinery, electronics, light industry, tobacco, chemical, pharmaceutical, rubber, motorcycle, logistics etc.
Automated Palletizing Conveyor Technical Parameter
| No. | Name | Brand/Model | Material |
| 1 | Motor | CPG | Aluminum alloy (shell) |
| 2 | Roller | Stick face diameter φ76, shaft φ28 | Galvanized |
| 3 | Outrigger | Channel steel: 100x48x5.3 | Carbon steel spray |
| 4 | Beam | Bending plate, thickness 5mm | Carbon steel spray |
| 5 | Chain | Defu//12A | Black |
Machine Models
| No. | Model | Name | Size | Note |
| 1 | XYR-DHA | Heavy pallet buffer conveyor A | Available width W=1240 | Adapt to pallet length 1000mm-1200mm |
| 2 | XYR-DHB | Heavy pallet buffer conveyor B | Available width W=1440 | Adapt to pallet length 1200mm-1400mm |
Options
Side guides;
End stop;
Caster wheel with brake;
Heavy duty adjustable feet can be anchored to the ground.
Features
Roller conveyor is composed of roller section, drive unit, chain, support etc. Under slung mounted motor drives above two rollers through chain, these two rollers will separately drive front and back rollers.
Product features
● simple structure, stable running, accord with international safety standard
● modular design, easy installation and maintenance
● big bearing surface, strong carrying capacity, long service life
● used in indoor pallet conveying
Drive
Standard conveyor is equipped with high quality reducer motor. Configuration position, output revolution and power etc of reducer motor are determined by working condition. Motor power depends on loading, conveyor speed and length etc. Common motor power can be 0.25, 0.37, 0.55, 0.75, 1.1, 1.5, 2.2 kw.
Specifications
Common length range: 1000~6000mm
Effective widths depend on goods size series;
Roller
Roller with high quality bearing can rotate smoothly, small resistance, low noise, long service life and galvanization treatment on roller surface.
Support
Adjustable foot is mounted at the bottom for height adjustment within the range of ±30mm.
Distance between supports is determined by working condition.
Speed
Normal speed can be 12, 16, 18m/min, maximum speed can be 20m/min.
Safety
There are guards for drive part of drive unit and roller sprocket. Put caution label on the places wherever injuries may take
place to remind and avoid accidents.
FAQ
Q:Are you a factory or a trade company?
A:We are the factory.
Q:Where are your products distributed?
A:Our products are distributed all over the world,main markets are Europe,North America, South America, the united Arab emirates, Africa and so on.
Q:Logistics?
A:1.Sea Shipment;
2.Air Shipment;
3.Transport by car or train;
4.Express:DHL,UPS,TNT.
Q:Payment?
A:T/T, VISA, Mastercard, L/C at sight, Alibaba trade assurance
