Product Details:
|
| Material Feature: | Heat Resistant | Roller Material: | Galvanized |
|---|---|---|---|
| Max Loading: | 2 Tons | Outrigger: | Carbon Steel Spray |
| Beam: | Bending Plate, Thickness 4-5mm | Installation: | Online Guide, Easy To Install |
| Power: | 0.75 / 1.5KW | Material: | Carbon Steel |
| Highlight: | 0.75KW gravity feed roller conveyor,0.75KW gravity roller table,380V gravity roller table |
||
380 V Bag Shaping Palletizing Conveyor In Beverage Industry , 0.75 KW
Roller Conveyor Application
The rollers machine is applicable to transport the goods whose bottom is flat. For example: electronic, beverage, food, packaging, machinery, electronics, light industry, tobacco, chemical, pharmaceutical, rubber, motorcycle, logistics etc.
Conveyor Type - Bag shaping conveyor
The product is conveyed by the vibration of the square roller, which makes the bag smoother, and the palletizing type on the pallet is neat and beautiful; at the same time, the shaping conveyor can pull the product apart at a certain distance, which is convenient for photoelectric detection and palletizing of the further station.
| No. | Model | Name | Size |
| 1 | XYR-ZXA | Bag shaping conveyor A | Length 2000mm, roller length 604mm, Height 750mm |
| 2 | XYR-ZXB | Bag shaping conveyor B | Length 2000mm, roller length 604mm, Height 1000mm |
| 3 | XYR-ZXC | Bag shaping conveyor C | Length 2000mm, roller length 604mm, Height 1200mm |
Technical Parameters
| No. | Name | Brand/Model | Material |
| 1 | Motor | CPG | Aluminum (shell) |
| 2 | Square roller | Square roller 80x80 | Carbon steel galvanized |
| 3 | Bearing block | LK | Cast iron |
| 4 | Outrigger | Square tube 80x40 | Carbon steel spray |
| 5 | Beam | Bent plate, thickness 4mm | Carbon steel spray |
| 6 | Guardrail | Bent plate, thickness 1.5mm | Stainless steel 201 |
Roller Conveyor Features
Roller conveyor is easy to link. And it can form a complex logistics conveyor system and shunt mixing system matched with multiple roller line and other conveying equipment.
It has the big transmission capacity, quick speed and fast running features, also can achieve more varieties of shunt conveying.
Options
Side guides;
End stop;
Caster wheel with brake;
Heavy duty adjustable feet can be anchored to the ground.
Our Service
1. one-year guarantee for whole machine
2. 24 hours technical support by e-mail
3. calling or door-to-door service
Package and Shipping
Machines are film wrapped and fixed in the exported wooden case. All the wooden cases will be transported to departure port warehouse to wait for loading in container or directly load in the container in our factory. All based on customer’s requirements.
Delivery: 7-15 working days after deposit.
FAQ
Q:How about your warranty?
A: Our warranty is 12 months. Normally, the general after-sale service may be as below:
The technical support is permanent.
The paid spares parts could be provided at any time.
We have agent in some countries to offer compensable service.
Q:Which port is the nearest ?
A:Shanghai, Ningbo, Guangzhou, Shenzhen
Q:What's your lead time ?
A:Normally 20-30 days after we receive your deposit.
